Heavy Duty Tie Straps  Heavy Duty Nylon Tie System

bulletStronger
bulletLighter Weight
bulletHighly Versatile Tie System
bulletAvailable in Any Length
bulletAvailable in 100' or 200' Rolls



The Heavy Duty Tie Strap is based on 6/6 nylon, is lighter, more flexible, and easier to handle than conventional metal or plastic ties of equal strength. In addition, the unique orientation process imparts excellent creep resistance over a wide temperature range compared to conventional plastic ties. Also available in handy 100' or 200' rolls of tie strap and bags of heads for unique versatility and quick application.

 Ultra-High-Strength Tie System Ideal for All Tie Applications

bullet400 lbs. (180 kg) loop tensile strength!
bullet2-piece system allows for virtually any length up to 30 feet or more.
bulletLowest creep over time.
bulletTie strap available in 100' or 200' rolls with separate heads.

Excellent Chemical & Electrical Properties

bulletExcellent solvent resistance.**
bulletContinuous operating temperature range from -40 to 190 F
bulletUL 94 V-2 rating.
bulletUV Resistant

Thinner, More Flexible, Easier to Install than Other Heavy Duty Ties

* Fastening of canisters, ducting, tubing, wire bundles, misc. packages, etc.
** Chemical resistance of 6/6 nylon.


NYLON TIE STRAPS - 1/2" x .036" - 400 lb loop strength - UV Resistant

Part Number

Length

Max. Bundle Dia. In.

Pcs per Bag

Bags/ Box

NT12150

12"

3"

50

20

NT18150

18"

5"

50

20

NT2F50

2'

7"

50

10

NT4F25

4'

14"

25

12

NT6F10

6'

18"

10

20

NT10F10

10'

37"

10

15

NT20F10

20'

75"

10

6

ACETAL TIE STRAPS - 1/2" x .050" - 400 lb loop strength - 20 year weatherable

Part Number

Length

Max.Bundle Dia. In.

Pcs per Bag

Bags/Box

AT12150

12"

3"

50

20

AT18150

18"

5"

50

20

AT2F50

2'

7"

50

20

AT4F25

4'

14"

25

12

AT6F10

6'

18"

10

20

AT10F10

10'

37"

10

15

AT20F10

20'

75"

10

6

INDIVIDUAL COMPONENTS - Rolls of strap & heads

Part Number

Description

Material

Pcs/Bag

Bags/Box

NH25E20

Head

Nylon

25

20

NH50E10

Head

Nylon

50

10

AH25E20

Head

Acetal

25

20

AH50E10

Head

Acetal

50

10

NR100F10

100' Roll

Nylon

-

10 rls/bx

NR200F10

200' Roll

Nylon

-

10 rls/bx

AR100F10

100' Roll

Acetal

-

10 rls/bx

AR200F10

200' Roll

Acetal

-

10 rls/bx

TIE STRAP KIT - Self-dispensing box - 100 ft strap & 25 heads

Part Number

Description

Material

-

Kits/box

NK100F25H

Kit- strap & heads

Nylon

-

20

#400

Tensioner tool for all Heavy Duty Tie Straps
